Tube Deep Fryer uses metal heating tubes that pass through the oil tank. Bene than those tubes are gas flames (in a gas model), which heat the tubes and therefore heat the oil around them.
-
These tubes are hollow and are part of the heating mechanism — instead of having just a burner under a flat pan, the heat is conducted via those tubes immersed in oil.
-
Underneath the heating tubes, there is often a “cold zone” — a region in the tank where the oil is cooler and where food debris (crumbs) can settle.
Performance & Use
-
High-output fryer: With a 150 MJ/h burner and a 44 L tank, it’s built for high-volume frying — ideal for commercial kitchens, fast food shops, takeaways, and restaurants.
-
Fast heat recovery: Because of the 5-burner/tube system, it can recover temperature quickly after adding food or baskets.
-
Oil life management: The design allows food particles (crumbs) to fall below the heating tubes into a "cold zone" — this helps reduce scorching and extends oil life.
-
Maintenance: The drain valve is large (32mm) and full-port, which reduces the chance of clogging during oil changes.
-
Cleaning: The fryer is designed to be serviceable from the front; basket hanger lifts off; lid is stainless-steel for easy cleaning.
-
Safety & reliability: Flame failure protection standard; standby pilot for easy start.
- Brand Name – Fry Max
- Dimensions – 533(W) x 759(D) x 1195(H)mm
- Manufacturer – Fry Max
- Oil Capacity 37 Litre
- Tank Capacity 44 Litre
- Natural Gas
- Stainless steel Front, door, tank and trim
- Temperature Range 120°C to 200°C
- Nett Weight 55kg
- 43kg/hr production rate
- 150MJ multi-jet burner system
- Reliable Millivolt Mechanical controls
- Easy clean, installation and service
- Supplied with 3 baskets
- Stainless steel lid supplied as standard
- ½ inch Gas Inlet
- Robshaw valve
- Built in Flue Deflector
- Flame Failure protection as standard
- Adjustable legs
- all components easily accessible and replaceable from the front
- Stainless steel basket hanger lifts off for easy cleaning
- Food particles fall below burner tubes into cold zone which increases oil life
- 32mm ball-type full port drain valve prevents clogging
- 2 Years Parts and Labour + 2 Years Parts only Warranty with Product Registration
